600G Muxponder / ADM

PL-4000M 600G Muxponder Interop Awards PacketLight's PL-4000M is a high capacity transport platform which aggregates a flexible mix of services into two 200/300/400G DWDM uplinks.

PL-4000M - 600G Muxponder

The PL-4000M is a cost-effective solution for rolling out multirate 10/25/100GbE, 16G FC, OTU2/2e/4 services, or increasing existing network capacity. The device delivers up to 600G in a 1U chassis using dual 400G CFP2-DCO Open ROADM standards-based pluggable coherent modules for metro and long haul applications.
High spectral efficiency
Multi services rates over 200G/300G/400G wavelengths using standards-based pluggable 400G DCO modules, with optional Layer-1 encryption.

The product meets market demands for low power consumption, rack space savings and reduction in the overall solution CAPEX and OPEX by increasing network capacity.

Please contact us for a quote or further assistance.

Download PL-4000M datasheet

Flexible Design

The PL-4000M provides full demarcation point between the service and the OTN/DWDM network, and is interoperable with any third party switch or router. This provides full visibility and performance monitoring of both line optical transport layer (OTN) and 10/25/100GbE, 16G FC, and OTU2/2e/4 service interfaces.

Powerful Feature Set

The PL-4000M delivers carrier grade, high-end 200G/300G/400G capacity per wavelength over two wavelengths, capable of serving multiple applications and protocols for enterprise and data center networks, such as data, storage, and OTN. The product supports standards-based Layer-1 encryption, configurable per service or per uplink.

PL-4000M Diagram

PL-4000M 400G Per Wavelength Muxponder

Please contact us for a quote or further assistance.

  • Flexible high capacity architecture based on 400G pluggable digital coherent optical modules
  • Supported clients: 10/25/100Gb Ethernet, 16G Fibre Channel, OTU2/2e/4
  • Flexible mix of client services mapped into a 200G/300G/400G DWDM wavelengths
  • Supports oFEC on the line side
  • Uplink: dual 200G/300G/400G CFP2-DCO Open ROADM pluggable coherent modules
  • Range of modulation modes: 16QAM, 8QAM, QPSKQ
  • Clients:
    • Up to 6 x QSFP28 for 100GbE or OTU4
    • 24 x SFP+ / SFP28 for lower rate services
  • Layer-1 GCM-AES-256 encryption, FIPS 140-3 Level 2 compliant
  • Elliptic Curve Diffie-Hellman key exchange
  • Supports quantum key distribution (QKD)
  • Comprehensive line and service performance monitoring
  • Integrated EDFAs pre-amp/booster (optional)
  • Facility protection using an integrated optical switch (optional)
  • OTN SNCP 1+1 service protection for ring applications
  • Remote management using in-band GCC orout-of-band OSC
  • Easy maintenance with field-replaceable parts:
    • Dual hot pluggable power supply units (AC/DC)
    • Fan unit
  • 300G/400G metro / long haul applications
  • 100G/200G long haul applications
  • High capacity DCI for enterprise, campus and cloud computingnetworks
  • 400G links to bolster existing OTN/DWDM infrastructure
  • Last mile access/aggregation CPE for 100GbE managed services
  • Secured and encrypted communication for 10/25/100GbE, 16G FC, and OTU2/2e/4 services
  • Cost-effective high capacity transport of 400G over single wavelength
  • Supports flexible mix of client interface protocols
  • Embedded Layer-1 GCM-AES-256 encryption
  • Integrated EDFAs and optical switch in 1U chassis
  • User-configurable 200G/400G operation mode
Note: For specific countries, models that include Layer-1 GCM-AES-256 based encryption will be marked with the suffix C.
