200G Single Wavelength Muxponder

PacketLight’s PL-2000M is a 200G multi-protocol multi-rate muxponder/transponder for building high capacity optical transport networks. Its flexible architecture enables the same device to be used in multiple applications and adapt to network growth and changes.

PL-2000M 200G Single Wavelength Muxponder

The PL-2000M provides high transport capacity of 200G over a single wavelength. The solution meets market demands for low power consumption and rack space savings, reducing overall CAPEX and OPEX and enabling to easily and cost-effectively roll-out service and increase capacity of enterprise DCI (data center interconnect) and metro networks.

Multi-service, multi-rates over 200G single wavelength
High spectral efficiency at affordable cost for DCI, enterprise, campus and cloud computing networks with optional Layer-1 encryption

The PL-2000M supports a flexible mix of 10GbE, 40GbE, 100GbE, 12G-SDI, and 8G/16G/32G FC services in various muxponder and transponder operation modes, combining different protocols and rates over a single 200G uplink.

Please contact us for a quote or further assistance.

PL-2000M One-pager

Flexible Design

The PL-2000M 1U device supports up to two integrated optical amplifiers and an optical switch. It is the smallest, most integrated transport solution of its kind, reaching up to 200km/42dB without intermediate sites and 1,000 km with inline sites.

Powerful Feature Set

The PL-2000M delivers carrier grade, high-end 200G solutions, capable of serving multiple applications and protocols for enterprise and data center networks, such as data, storage, video, and TDM (time-division multiplexing). The product supports standards-based Layer-1 encryption, configurable per service or per uplink.

PL-2000M Diagram

PL-2000M 200G Single Wavelength Muxponder Diagram

Please contact us for a quote or further assistance.

  • User-configurable muxponder and transponder operation modes
  • Supported clients: 10GbE, 40GbE, 100GbE, 12G-SDI, 8G/16G/32G Fibre Channel, OC-192/STM-64 SONET/SDH, OTU2/OTU2e/OTU3/OTU4 OTN
  • 200G uplink aggregation, using any mix, for example:
    • Up to 20 x 10GbE (multi-rate) clients
    • 2 x 100GbE clients
    • 1 x 100GbE + 10 x 10GbE clients
    • 4 x 40GbE + 4 x 10GbE clients
  • Forward error correction (FEC):
    • Standard ITU-T G.709 GFEC
    • SD-FEC
  • Operation modes:
    • 16QAM 200G metro ~650km
    • DP-QPSK 100G long haul ~4000km
  • 200G pluggable CFP2 coherent (ACO) tunable DWDM line interface
  • Layer-1 GCM-AES-256 encryption
  • FIPS 140-2 Level 2 certified
  • Common Criteria EAL2 certified
  • CNSA Top Secret Suite B 2015 compliant
  • Diffie-Hellman key exchange
  • Supports quantum key distribution (QKD)
  • Comprehensive line and service performance monitoring
  • Optional integrated booster and/or preamp EDFA
  • Facility protection using an optional integrated optical switch
  • Remote management with in-band, GCC or out-of-band OSC
  • Dual AC or DC pluggable power supply and pluggable fan unit
  • Supports standard MSA pluggable SFP+, SFP28, QSFP+, QSFP28 and CFP2
  • Hight conformance 100G for alien wavelength applications
  • Metro network applications ranging up to 1,000 km
  • High capacity DCI for enterprise, campus and cloud computing networks
  • 200G links to bolster existing OTN/DWDM infrastructure
  • Last mile access/aggregation CPE for 10GbE, 40GbE, and 100GbE managed services
  • Secured and encrypted communication for all protocols
  • 200G capacity over single wavelength
  • Drives cost efficiency for high capacity networks
  • Highly integrated 1U solution
  • User-configurable muxponder and transponder operating modes
  • Supports 10GbE, 40GbE, and 100GbE services and protocol mix
  • Embedded GCM-AES-256 encryption for all protocols
  • User-configurable 100G/200G operation mode
  • Low power consumption
FIPS 140-2 Level 2 Certified Common Criteria EAL2 Certified
Note: For specific countries, models that include Layer-1 GCM-AES-256 based encryption will be marked with the suffix C.
